Turbine Housing:

Quantity:

Email this page to a friend

Price: $1,449.99

Manufacturer: Garrett

Part No.: GT3076R

	Ball bearing
*	Oil & Water-cooled bearing system
*	Upgrade turbocharger for GT3071R non-wastegated ball-bearing turbocharger; turbine housing flanges are outline interchangeable
*	T3 turbine inlet flange
*	Ideal for medium displacement engines making up to 525 hp
*	Turbine housing kit options available

Price Includes a Turbine Housing Kit, and complete turbocharger ready to go.

Ball bearing

GT3076R

COMPRESSOR

TURBINE

Turbo		CHRA
700382-12		700177-7

Wh Dia		Trim	A/R
Ind	Exd
57.0mm	76.2mm	56	0.60

	Wh Dia		Trim		A/R		Type
	60mm		84		see below		see below

TURBINE HOUSING OPTION

Part Number
740902-1
740902-2
740902-3
740902-7
740902-8
740902-9
740902-13
740902-14
740902-15

Wh Dia	Trim	A/R	Type
-	-	1.06	Free Float
-	-	0.82	Free Float
-	-	0.63	Free Float
-	-	1.06	Free Float
-	-	0.82	Free Float
-	-	0.63	Free Float
-	-	1.06	Free Float
-	-	0.82	Free Float
-	-	0.63	Free Float

The 700382-12 GT30R is a customizable Garrett ball bearing GT turbo that is packaged without the turbine housing. (It includes a CHRA and compressor housing.) Turbine housing kit options 740902-1, 740902-2, or 740902-3 feature a 4-bolt turbine outlet. Turbine housing kit options 740902-13, 740902-14, and 740902-15 feature a 90mm V-band outlet.

The turbine housing kits include turbine housing, clamps, bolts, and turbine inlet gasket.
